VIR-300 NIR Spectrometer
£0.00
- NIR interferometer for a wide range of near-infrared applications.
- Optional sampling systems include a fiber optic interface with sample probes and a range of diffuse reflectance accessories for quality control applications
- NIR configuration with CaF2 beam splitter and halogen light source
- Spectral range: 15,000 to 2,200 cm-1
- Maximum resolution 0.4 – 16 cm-1
Availability:
In stock
SKU
VIR-300
VIR-300 NIR Spectrometer
The VIR Series rugged FTIR spectrometer is compact and lightweight, making it easily transportable. The collimated entrance and exit ports make it an ideal instrument for a wide range of user-designed experiments. The standard instrument includes a hermetically sealed interferometer, DLaTGS detector, high intensity ceramic light source, KRS-5 windows and automatic alignment. Options are available for increased sensitivity, optional spectral ranges including NIR, and battery operation.
System Features
- Three models: VIR-100, VIR-200, and VIR-300
- Operate with a laptop or desktop using Spectra Manager Suite
- 45 deg Michelson sealed interferometer with KRS-5 windows and light-weight gold-coated corner-cube mirrors
- DLaTGS detector (standard) MCT and InGaAs (Options)
- ‘Learning’ antivibration system for the moving-mirror for use in industrial environments
- Automatic locking moving mirror
- Accessories for ATR, transmission and diffuse or specular reflectance
- Customizable for in-situ measurements in factory or field locations
- Multiple configuration of up to three accessories on one spectrometer with external connection optics
- Universal optical base allowing users to build customized systems
- Eco-friendly system including sleep-mode as well as a compact & space-saving design
- High-speed monitoring with optional 40 Hz Rapid Scan
- Comprehensive self-diagnostics & validation
- USB connection (with optional USB to ethernet connection).
